Tube Clamp Handrailing System & Fittings

All fittings for any tube handrail, plus galvanised tube cut to any length.

Galvanised tube and handrail fittings in all sizes for simple fabrication of handrails, safety barriers and rack systems for storage.
May also be used for quick and easy construction of stages and platforms for events.

We are happy guide you through your selection of fittings to ensure that you order exactly what you need.

Galvanised Tube

1.044m to 6.5m or cut to special size

SPECIAL OFFER!
CARRIAGE ONLY £10!

TUBE SIZES
A Tube: 26.9mm dia
B Tube: 33.7mm dia
C Tube: 42.4mm dia
D Tube: 48.3mm dia
E Tube: 60.3mm dia


galvanised steel tubing



1 inch
=
25.4mm or 2.54cm

1 foot
=
304.8mm or 30.48cm

1 yard
=
914.4mm or 91.44cm

Tube Clamp Fitting Top 1:
LONG TEE

LONG TEE - key clamp handrail fitting

(For A/B/C/D/E Tube)

For use on straight and level guardrail to connect the upright to the top rail. Tubes may be joined inside this fitting. Normally used in conjunction with the 'MIDDLE 1 INTERSECTION' fitting when building double rail handrail or guardrail.


Tube Clamp Fitting Top 3:
CORNER

CORNER - key clamp handrail fitting

(For A/B/C/D/E Tube)

For use on straight and level guardrail to connect the two top rails to the upright at a 90° corner post. Normally used in conjunction with the 'MIDDLE 3 CORNER INTERSECTION' fitting when building double rail handrail or guardrail.


Tube Clamp Fitting Top 7:
SWIVEL TEE

SWIVEL TEE - key clamp handrail fitting

(For A/B/C/D/E Tube)

Used mainly for sloping handrails, this swivel pivots at least 80° from the fitting in either direction.


Tube Clamp Fitting Elbow 1:
90° ELBOW

90º ELBOW - key clamp handrail fitting

(For A/B/C/D/E Tube)

For use on straight and level guardrail to connect the top rail to the upright. Normally used in conjunction with the 'MIDDLE 2 SIDE TEE' fitting when building an end post on a double rail handrail or guardrail. This 2 way elbow can also be used to create a 90° bend.


Tube Clamp Fitting Elbow 2:
VARIABLE ELBOW

VARIABLE ELBOW - key clamp handrail fitting

(For B/C/D Tube)

For connecting two tubes at angles of 15°-60° on guardrails or handrails. Using this fitting means it is not necessary to bend tube.


Tube Clamp Fitting Middle 1:
INTERSECTION

INTERSECTION - key clamp handrail fitting

(For A/B/C/D/E Tube)

For use on straight and level guardrail to connect the mid rails to the upright. The upright must remain continuous with the cross rails being cut. Normally used in conjunction with the 'TOP 1 LONG TEE'' fitting when building double rail handrail or guardrail.


Tube Clamp Fitting Middle 2:
SIDE TEE

SIDE TEE - key clamp handrail fitting

(For A/B/C/D/E Tube)

For use on straight and level guardrail to connect the upright to the top rail or the end or mid rail to the upright. Do not join tubes inside this short tee - use a 'TOP 1 LONG TEE' fitting. Normally used in conjunction with the 'MIDDLE 1 INTERSECTION' when building double rail handrail or guardrail.


Tube Clamp Fitting Middle 3:
CORNER INTERSECTION

CORNER INTERSECTION - key clamp handrail fitting

(For A/B/C/D/E Tube)

For use on straight and level guardrail to connect the mid rails to the upright at a 90° corner. Normally used in conjunction with the 'TOP 3 CORNER' when building double rail handrail or guardrail.


Tube Clamp Fitting Middle 5:
ADJUSTABLE CROSS 30-45°

ADJUSTABLE CROSS 30º-45º - key clamp handrail fitting

(For B/C/D Tube)

For use on steeper slopes or stairs as an intermediate cross connector with an angle of 30°-45° with the upright remaining vertical. Normally used in conjunction with the '129: ADJUSTABLE SHORT TEE 30-60°' when building double rail handrail or guardrail. This adjustable cross fitting is not recommended for use as the top fitting on handrail or guardrail.


  Tube Clamp Fitting Middle 7:
DOUBLE SWIVEL COMBINATION

DOUBLE SWIVEL COMBINATION - key clamp handrail fitting

(For A/B/C/D Tube)

Typically used on sloping handrail/guardrail. This fitting combines 1 x 167M & 2 x 173F. The swivels can travel approximately 85° from the horizontal in both directions. NOT DESIGNED TO WITHSTAND LATERAL LOADS. AN ENTIRE STRUCTURE SHOULD NOT BE BUILT USING ONLY SWIVEL FITTINGS, THIS WOULD BE UNSTABLE.


Tube Clamp Fitting Middle 8:
SIDE OUTLET TEE

SIDE OUTLET TEE - key clamp handrail fitting

(For A/B/C/D/E Tube)

For constructing market stall or play frame type structures.


Galvanised Tube

1.044m to 6.5m or cut to special size

SPECIAL OFFER!
CARRIAGE ONLY £10!

TUBE SIZES
A Tube: 26.9mm dia
B Tube: 33.7mm dia
C Tube: 42.4mm dia
D Tube: 48.3mm dia
E Tube: 60.3mm dia


Tube Clamp Fitting Middle 12:
RAMP TEE

RAMP TEE - key clamp handrail fitting

(For D Tube)

Ramp tee fitting designed for use on ramps or other shallow gradients between 4-10°.

£8.66

Tube Clamp Fitting Base 1:
RAILING BASE FLANGE

RAILING BASE FLANGE - key clamp handrail fitting

(For A/B/C/D/E Tube)

A structural base plate for all applications using vertical posts. For guardrail the fitting should be positioned with the base holes at 90° to the line of the rail to give maximum strength.


Tube Clamp Fitting Base 2:
WALL BASE

WALL BASE - key clamp handrail fitting

(For A/B/C/D/E Tube)

For terminating cross rails to walls etc. It may also be used as a base plate for non-load bearing structures such as chairs, benches, tables etc. DO NOT USE AS A BASE PLATE FOR HANDRAIL/GUARDRAIL OR IN LOAD BEARING APPLICATIONS.


Tube Clamp Fitting Base 3:
SIDE BASE

SIDE BASE - key clamp handrail fitting

(For B/C/D Tube)

For use as an offset structural side palm fixing for either straight or sloping guardrail. The tube is unable to pass through the standard fitting - should this be required then the base must be reamed out. Use in conjunction with a 'BASE 7 WALL HANDRAIL BASE' when a secondary inline base fixing is required.


Tube Clamp Fitting Base 4:
TRIANGULAR SIDE BASE

TRIANGULAR SIDE BASE - key clamp handrail fitting

(For B/C/D Tube)

For use as a structural side palm fixing for the upright on either straight or sloping handrail or guardrail keeping the upright as close as possible to the slope or stairs. When used as a secondary inline fixing the base needs to be machined to allow the tube to pass through and the bottom fixing hole then becomes redundant. BASE THICKNESS 7MM.


Tube Clamp Fitting Base 5:
WALL SWIVEL SIDE BASE

WALL SWIVEL SIDE BASE - key clamp handrail fitting

(For A/B/C/D/E Tube)

Non-structural male locating swivel. This fitting combines 1 x 169M & 1 x 173F. The swivel can travel approximately 85° from the horizontal in both directions. NOT TO BE USED AS A BASE PLATE FOR GUARDRAIL AND NOT DESIGNED TO WITHSTAND LATERAL LOADS.


Tube Clamp Fitting Base 6:
SIDE BASE

SIDE BASE - key clamp handrail fitting

(For B/C/D Tube)

Designed to provide a base for railings and other structures that need a side mounted flush fixing plate. When used as a secondary inline fixing the base needs to be reamed out to allow the tube to pass through.


Tube Clamp Fitting Base 7:
WALL HANDRAIL BASE

WALL HANDRAIL BASE - key clamp handrail fitting

(For B/C/D Tube)

For wall mounted handrailing, this fitting can also be used to hold in place kick plate on guardrail, or even display boards at exhibitions. DO NOT USE AS A SOLITARY BASE PLATE FOR HANDRAIL/GUARDRAIL OR SIMILAR LOAD BEARING APPLICATIONS.


Tube Clamp Fitting Base 8:
GROUND BASE

GROUND BASE - key clamp handrail fitting

(For B/C/D Tube)

For use as a base plate for a removable upright that can be removed without leaving any obstructions. The tube is held in place by the setscrew. The casting hole should be a minimum 300x300x300mm.


Tube Clamp Fitting Base 9:
WEATHER COVER SHIELD

WEATHER COVER SHIELD - key clamp handrail fitting

(For B/C/D Tube)

For weather protection around a 'BASE 1: RAILING BASE FLANGE' on a flat roof guardrail system. This fitting needs to be sealed with a suitable sealant.


Tube Clamp Fitting Base 10:
SWIVEL BASE SECTION

SWIVEL BASE SECTION - key clamp handrail fitting

Non-structural male locating base, typically used to create a swivel base. NOT DESIGNED TO WITHSTAND LATERAL LOADS.

£4.78


Tube Clamp Fitting Crossover 8:
FOUR WAY CROSS

4 WAY CROSS - key clamp handrail fitting

(For A/B/C/D/E Tube)

For joining tubes together in the centre of a structure. This four way cross fitting allows the upright to pass through the centre with the cross rails joining at 90° to the upright.


Tube Clamp Fitting Crossover 9:
CLAMP ON CROSSOVER

CLAMP ON CROSSOVER - key clamp handrail fitting

Clamp on Crossover
(For A/B/C/D Tube)

For adding to an existing offset structure without the need for any dismantling.




Tube Clamp Fitting Connector 1:
EXTERNAL CONNECTOR

EXTERNAL CONNECTOR - key clamp handrail fitting

(For A/B/C/D/E Tube)

Inline external connector for joining two tubes together in a run. For an inline joint that is the same diameter as the tube, the 'CONNECTOR 2 INTERNAL CONNECTOR' fitting should be used. Not recommended as a structural joint.


Tube Clamp Fitting Connector 2:
INTERNAL CONNECTOR

INTERNAL CONNECTOR - key clamp handrail fitting

(For B/C/D Tube)

Inline internal connector for joining two tubes together. Only for use with medium gauge 3.2mm wall thick tube. This joint should never be used as a load bearing joint and must be used within 100mm of an upright.


Tube Clamp Fitting Connector 3:
MESH PANEL CLIP - SINGLE

SINGLE MESH PANEL CLIP - key clamp handrail fitting

(For A/B/C/D Tube)

For retaining weld mesh panels into handrail/guardrail. To correctly retain the weld mesh panel in place using this clip, the mesh should be framed with an 8mm bar. Supplied with stainless steel hexagonal head screw and nut.


Tube Clamp Fitting Connector 4:
MESH PANEL CLIP - DOUBLE

DOUBLE MESH PANEL CLIP - key clamp handrail fitting

(For B/C/D Tube)

For retaining weld mesh panels into handrail/guardrail. To correctly retain the weld mesh panel in place using this clip, the mesh should be framed with a 8mm bar. Supplied with stainless steel hexagonal head screw and nut.

Galvanised Tube

1.044m to 6.5m or cut to special size

SPECIAL OFFER!
CARRIAGE ONLY £10!

TUBE SIZES
A Tube: 26.9mm dia
B Tube: 33.7mm dia
C Tube: 42.4mm dia
D Tube: 48.3mm dia
E Tube: 60.3mm dia


Tube Clamp Fitting Support:
LOCKING COLLAR

LOCKING COLLAR - key clamp handrail fitting

(For B/C/D Tube)

For providing additional strength to fittings on high load structures.


Tube Clamp Fitting Hinge 7:
EYE PART

EYE PART - key clamp handrail fitting

(For B/C/D Tube)

Female section of a two-part gate hinge, used in conjunction with the 'HINGE 8 HOOK PART' fitting.


Tube Clamp Fitting Hinge 8:
HOOK PART

HOOK PART - key clamp handrail fitting

(For B/C/D Tube)

Male section of a two-part gate hinge, used in conjunction with the 'HINGE 7 EYE PART' fitting.


Tube Clamp Fitting Hook 9

CHAIN HOOK PART - key clamp handrail fitting

(For B/C/D Tube)

This chain hook is not recommended as a permanent chain location - for permanent chain locations one end should be retained in place using a '173M: SINGLE SWIVEL COMBINATION' and fixed with a nut and bolt.


Tube Clamp Fitting PLUG

END CAP PLUG - key clamp handrail fitting

(For A/B/C/D/E Tube)

A plastic end cap to seal the open end of tubes. This fitting is a frictional fit only. For a permanent fix, a suitable adhesive should be used.


Tube Clamp Fitting 129
ADJUSTABLE SHORT TEE

ADJUSTABLE SHORT TEE - key clamp handrail fitting

(For B/C/D Tube)

Adjustable fitting between 30-60°. Typically used as a tee connection on steeper stairs and slopes with a vertical upright. May also be used as a structure bracing.


Tube Clamp Fitting 135
CLAMP ON TEE

CLAMP ON TEE - key clamp handrail fitting

(For A/B/C/D/E Tube)

For adding to an existing inline structure without having to dismantle the original structure. MAXIMUM BOLT TORQUE 15N/M. Uses a M10 stainless steel bolt.


Tube Clamp Fitting 141
RAILING SIDE SUPPORT HORIZONTAL

RAILING SIDE SUPPORT HORIZONTAL - key clamp handrail fitting

(For B/C/D Tube)

The Railing Horizontal Side Support is designed to provide a base for railings and other structures that need a side mounted flush fixing plate. When used as a secondary inline fixing the base needs to be reamed out to allow the tube to pass through.


Tube Clamp Fitting 144
RAILING SIDE SUPPORT VERTICAL BASE

RAILING SIDE SUPPORT VERTICAL BASE - key clamp handrail fitting

(For B/C/D Tube)

For use as an offset structural side palm fixing for either straight or sloping guardrail. The tube is unable to pass through the standard fitting - should this be required then the base must be reamed out. Use in conjunction with a 'BASE 7 WALL HANDRAIL BASE' when a secondary inline base fixing is required.


Tube Clamp Fitting 147
INTERNAL SWIVEL TEE

INTERNAL SWIVEL TEE - key clamp handrail fitting

(For B/C/D Tube)

For offset variable angle sloping handrail or guardrail in conjunction with a 'MIDDLE 2 SIDE TEE' or 'ELBOW 1 90° ELBOW' fitting.


Tube Clamp Fitting CROSSOVER 9

CLAMP ON CROSSOVER - key clamp handrail fitting

(For A/B/C/D/E Tube)

Ideal for retrofitting a horizontal piece to existing railings or structure. Useful when dismantling of the original construction would be difficult.


Tube Clamp Fitting 161
90° ADD ON CROSSOVER

90º CROSSOVER - key clamp handrail fitting

(For A/B/C/D/E Tube)

Allows additions to existing structures without the need for any dismantling. This 90° crossover is designed to give a 90° offset crossover joint. The tubes may not be joined within this fitting.


Tube Clamp Fitting 165
COMBINATION SOCKET TEE

COMBINATION SOCKET TEE - key clamp handrail fitting

(For A/B/C/D/E Tube)

Typically used for the construction of pallet racking or shelved racking systems. Tubes may not be joined inside this fitting.


Tube Clamp Fitting 167
DOUBLE SWIVEL COMBINATION

DOUBLE SWIVEL COMBINATION - key clamp handrail fitting

(For A/B/C/D Tube)

Typically used on sloping handrail/guardrail. This fitting combines 1 x 167M & 2 x 173F. The swivels can travel approximately 85° from the horizontal in both directions. NOT DESIGNED TO WITHSTAND LATERAL LOADS. AN ENTIRE STRUCTURE SHOULD NOT BE BUILT USING ONLY SWIVEL FITTINGS, THIS WOULD BE UNSTABLE.


Tube Clamp Fitting 167M
DOUBLE MALE SECTION

DOUBLE MALE SECTION - key clamp handrail fitting

(For A/B/C/D/E Tube)

Double male fitting with the connection lugs at 180° to each other. This fitting can also be used to retain display panels etc. NOT DESIGNED TO WITHSTAND LATERAL LOADS.


Tube Clamp Fitting 168
CORNER SWIVEL

CORNER SWIVEL - key clamp handrail fitting

(For A/B/C/D Tube)

For use with sloping handrail/guardrail. This fitting combines 1 x 168M & 2 x 173F. The swivels can travel approximately 85° from the horizontal in both directions. NOT DESIGNED TO WITHSTAND LATERAL LOADS. AN ENTIRE STRUCTURE SHOULD NOT BE BUILT USING ONLY SWIVEL FITTINGS, THIS WOULD BE UNSTABLE.


Tube Clamp Fitting
IN LINE SWIVEL FITTING

INLINE SWIVEL FITTING - key clamp handrail fitting

(For B/C/D Tube)

Variable angle in-line connection with an adjustable range of up to 200°.

Tube Clamp Fitting 142
TOEBOARD ADAPTOR

TOEBOARD ADAPTOR - key clamp handrail fitting

(For D Tube)

Ideal for guardrailing and balustrading applications where the addition of a toeboard or kick plate is required. Slotted holes in the back plate allow for sideways movements to ease installation.

£14.38

Galvanised Tube

1.044m to 6.5m or cut to special size

SPECIAL OFFER!
CARRIAGE ONLY £10!

TUBE SIZES
A Tube: 26.9mm dia
B Tube: 33.7mm dia
C Tube: 42.4mm dia
D Tube: 48.3mm dia
E Tube: 60.3mm dia


Tube Clamp Fitting 168M
90° CORNER SWIVEL MALE

90º CORNER SWIVEL MALE - key clamp handrail fitting

(For A/B/C/D Tube)

Double male fitting with the connection lugs at 90° to each other. This fitting can also be used to retain display panels etc. NOT DESIGNED TO WITHSTAND LATERAL LOADS.


Tube Clamp Fitting 173F
FEMALE SWIVEL SECTION

FEMALE SWIVEL SECTION - key clamp handrail fitting

(For C/D Tube)

Used in conjunction with the male fittings 167M, 168M, 169M & 173M. NOT DESIGNED TO WITHSTAND LATERAL LOADS.


Tube Clamp Fitting 174
SWIVEL TEE

SWIVEL TEE - key clamp handrail fitting

(For D Tube)

A versatile swivel fitting, often used for braces and where staircase middle rails join level sections. Tubes should not be joined within this fitting.

£19.08

Tube Clamp Fitting 175
SWIVEL ELBOW

SWIVEL ELBOW - key clamp handrail fitting

(For D Tube)

A versatile swivel fitting, often used where top rails join level sections, or for braces.

£18.36

Tube Clamp Fitting 184
45° TEE

45º TEE - key clamp handrail fitting

(For B/C/D Tube)

A bracing and strut component to strengthen structures.


Tube Clamp Fitting 185
EAVES FITTING

EAVES FITTING - key clamp handrail fitting

(For D Tube)

Used on the eaves end of a roof system in conjunction with the '191: RIDGE FITTING'.

£18.42

Tube Clamp Fitting 123
VARIABLE ELBOW 40-70°

VARIABLE ELBOW 40-70° - key clamp handrail fitting

(For D Tube)

Mainly for use at the top of a stairway decline. Variable angle between 40- 70°.

£15.24

Tube Clamp Fitting 750
ASSIST EXPANDING FITTING

ASSIST EXPANDING FITTING - key clamp handrail fitting

(For D Tube)

£15.48

Tube Clamp Fitting 9931
PALLET FLANGE

PALLET FLANGE - key clamp handrail fitting

(For D Tube)

Ideal for the construction of post pallets, with sockets for the upright and side tubes, plus locating bell for pallet stacking.

£47.88

Tube Clamp Fitting 191
RIDGE FITTING

RIDGE FITTING - key clamp handrail fitting

(For D Tube)

Used on the ridge of a roof system in conjunction with the '185: EAVES FITTING'.

£16.02

Tube Clamp Fitting 199
ADJUSTABLE FIXING BRACKET

ADJUSTABLE FIXING BRACKET - key clamp handrail fitting

(For C/D Tube)

For fixing panels, display boards or flooring to structures. Supplied with a pre-drilled hole.


Tube Clamp Fitting A101
ADD ON SHORT TEE

ADD ON SHORT TEE - key clamp handrail fitting

(For C/D Tube)

This fitting allows existing structures to be extended without any need for dismantling. The tube must not be joined within the add on short tee.


Tube Clamp Fitting A161
90° ADD ON CROSSOVER

90° ADD ON CROSSOVER - key clamp handrail fitting

(For C/D Tube)

90° bolt-on joint ideal for making additions or alterations to an existing structure where a 'CROSSOVER 7' cannot be used. Tubes should not be joined within the fitting.


  Tube Clamp Fitting 130
ADJUSTABLE 2 SOCKET CROSS 30-45°

ADJUSTABLE 2 SOCKET CROSS 30-45º - key clamp handrail fitting

(For B/C/D Tube)

For use on steeper slopes or stairs as an intermediate cross connector with an angle of 30-45° with the upright remaining vertical. Normally used in conjunction with the '129: ADJUSTABLE SHORT TEE 30-60°' when building double rail handrail or guardrail. This adjustable cross fitting is not recommended for use as the top fitting on handrail or guardrail.


Tube Clamp Fitting 151
ANGLE BASE FLANGE 11-30°

ANGLE BASE FLANGE 11-30º - key clamp handrail fitting

(For C/D Tube)

Similar to the '152: BASE FLANGE FOR SLOPE UP TO 11°', this fitting is used to set the upright at an angle of 11º–30º. This fitting should only be subjected to light loads which cannot be positioned at 90º to the applied load. For greater loads or other tube sizes a 'BASE 1 TALL BASE' should be used with the upright bent to the required angle.


Tube Clamp Fitting 177
THREE SOCKET TEE 11-30°

THREE SOCKET TEE 11-30º - key clamp handrail fitting

(For C/D Tube)

For use on safety railing with slopes of 11-30º, fixing the top rail to a vertical intermediate upright.


Tube Clamp Fitting 178
TWO SOCKET CROSS 11-30°

TWO SOCKET CROSS 11-30º - key clamp handrail fitting

(For C/D Tube)

Used on safety railing with slopes of 11-30º, fixing the mid rail to a vertical intermediate upright.


RETURN BEND 33.7MM - key clamp handrail fitting

HBend25113
Return Bend 33.7mm

300mm legs. Self colour.

£POA

STAIR RETURN BEND 33.7MM - key clamp handrail fitting

HBend25124
Stair Return Bend 33.7mm

400mm legs. Self colour.

£POA

HANDRAIL RAMP BEND 33.7MM - key clamp handrail fitting

HBend25135
Handrail Ramp Bend 33.7mm

500mm legs. Self colour.

£POA

HANDRAIL 90º BEND 33.7MM - key clamp handrail fitting

HBend25143
Handrail 90° Bend 33.7mm

300mm legs. Self colour.

£POA

HANDRAIL STANDARD RETURN BEND 33.7MM - key clamp handrail fitting

HBend25213
Handrail Standard Return Bend 33.7mm

25NB. 300mm legs. Galvanised.

£POA

HANDRAIL STANDARD RETURN BEND 33.7MM - key clamp handrail fitting

HBend25214
Handrail Standard Return Bend 33.7mm

400mm legs. Galvanised.

£POA

HANDRAIL STANDARD STAIR RETURN BEND 33.7MM - key clamp handrail fitting

HBend25224
Handrail Standard Stair Return Bend 33.7mm

400mm legs. Galvanised.

£POA

HANDRAIL STANDARD RAMP BEND 33.7MM - key clamp handrail fitting

HBend25235
Handrail Standard Ramp Bend 33.7mm

500mm legs. Galvanised.

£POA

HANDRAIL STANDARD 90º BEND 33.7MM - key clamp handrail fitting

HBend25243
Handrail Standard 90° Bend 33.7mm

300mm legs. Galvanised

£POA

HANDRAIL STANDARD RETURN BEND 42.4MM - key clamp handrail fitting

HBend32213
Handrail Standard Return Bend 42.4mm

32NB. 300mm legs. Galvanised.

£POA

HANDRAIL STANDARD STAIR RETURN BEND 42.4MM - key clamp handrail fitting

HBend32224
Handrail Standard Stair Return Bend 42.4mm

400mm legs. Galvanised.

£POA

HANDRAIL STANDARD 90º BEND 42.4MM - key clamp handrail fitting

HBend32243
Handrail Standard 90° Bend 42.4mm

300mm legs. Galvanised.

£POA

Handrail slope fittings

For railings required on slopes and ramps between 0-11°.

Available to suit tube 'D' (Ø48.3mm).

NB. The tolerance on standard fittings is between 3-5°.

slope fittings for key clamp handrailings
Tube Clamp Fitting 152
BASE FLANGE FOR SLOPE UP TO 11°

Base flange for slope up to 11° - key clamp handrail fitting

Fits 'D' tube only

For use as a structural base for sloping handrail or guardrail of 0-11° enabling the upright to remain vertical.

£14.34

Tube Clamp Fitting 153
SHORT TEE FOR SLOPE UP TO 11°

Short tee for slope up to 11° - key clamp handrail fitting

Fits 'D' tube only

For use on shallow sloping handrail or guardrail of 0-11° to connect the upright to the top rail or the end or mid rail to the upright. Normally used in conjunction with the '154: ELBOW FOR SLOPE UP TO 11°. Tubes may not be joined inside this fitting - to join tubes use the '155: LONG TEE FOR SLOPE UP TO 11°'.

£8.66

Tube Clamp Fitting 154
ELBOW FOR SLOPE UP TO 11°

Elbow for slope up to 11° - key clamp handrail fitting

Fits 'D' tube only

For use on shallow sloping handrail or guardrail of 0-11° at the start or end of a run to connect the upright to the top rail. This elbow may be used at either the bottom or top of an incline. Normally used in conjunction with the '153: SHORT TEE FOR SLOPE UP TO 11°' fitting.

£11.34

Tube Clamp Fitting 155
LONG TEE FOR SLOPE UP TO 11°

Long tee for slope up to 11° - key clamp handrail fitting

Fits 'D' tube only

For use on shallow sloping handrail or guardrail of 0-11° to connect the upright to the top rail. Tubes may be joined inside this fitting. Normally used in conjunction with the 156: TWO SOCKET CROSS FOR SLOPE UP TO 11°' fitting.

£13.50

Tube Clamp Fitting 156
TWO SOCKET CROSS FOR SLOPE UP TO 11°

Two socket cross for slope up to 11° - key clamp handrail fitting

Fits 'D' tube only

For use on shallow sloping handrail or guardrail of 0-11° to connect the mid or lower rails to the upright. The upright must remain continuous with the cross rails cut. Normally used in conjunction with the '155: LONG TEE FOR SLOPE UP TO 11°' fitting.

£13.50

Tube Clamp Fitting
GRUB SCREWS

GRUB SCREWS for key clamp handrail fittings

(For A/B/C/D/E Tube)

Proprietary coated, case hardened setscrews. When tightened to a torque of 39Nm they give a slip load of 900kg to a safety factor of 2.


Tube Clamp Fitting
ALLEN KEY

ALLEN KEY for key clamp handrail fittings

(For A/B/C/D/E Tube)

Hexagonal Allen Key - the only tool required to tighten up a setscrew.


Galvanised Tube

1.044m to 6.5m or cut to special size

SPECIAL OFFER!
CARRIAGE ONLY £10!

TUBE SIZES
A Tube: 26.9mm dia
B Tube: 33.7mm dia
C Tube: 42.4mm dia
D Tube: 48.3mm dia
E Tube: 60.3mm dia


Pre-fabricated Safety Gate with Posts - left handed - 42.4mm Tube - Self Closing

Pre-fabricated safety gate with posts - left handed
42.4mm tube - self closing

FSG-LH-42

£178.80

Pre-fabricated Safety Gate with Posts - right handed - 42.4mm Tube - Self Closing

Pre-fabricated safety gate with posts - right handed
42.4mm tube - self closing

FSG-RH-42

£178.80

gate hinge kit

Hinge Kit For Safety Gate - stainless steel

Stainless steel hinge kit for safety gate

HKFSG-SS

For Welding To Round S/S Tube Sections

• Adjustable closing speed
• Plate with slotted pin
• Plate with pin hole
• Plain plate
• Spring and lock nut
• M8 x 20 countersunk screws
• Washers

£220.00

Hinge Kit For Safety Gate - stainless steel

Stainless steel hinge kit for safety gate

HKFSG-T

For Welding To Tubular Sections

• Adjustable closing speed
• Plate with slotted pin
• Plate with pin hole
• Plain plate
• Spring and lock nut
• M8 x 20 countersunk screws
• Washers

£118.00

Hinge Kit For Safety Gate - stainless steel

Stainless steel hinge kit for safety gate

HKFSG-SQ

For Welding To Square Section

• Adjustable closing speed
• Plate with slotted pin
• Plate with pin hole
• Plain plate
• Spring and lock nut
• M8 x 20 countersunk screws
• Washers

£118.00

SPRUNG GATE HINGE DIAGRAM

Hinge Kit For Safety Gate - suits tubular sections

Hinge kit for safety gate

25SGH

For Welding To Tubular Sections

£80.34

Hinge Kit For Safety Gate - suits square sections

Hinge kit for safety gate

25SGHS

For Welding To Square Sections

£80.34

Rubber Gate Bump Stop

Rubber Gate Bump Stop

Dia 20mm x L 25mm

£7.14

Galvanised Tube Handrail Standard
2B-550-550

Galvanised Tube Handrail Standard for M16 bolts

10mm flat drilled ø18 holes
for M16 bolts
(For B/C/D Tube)


Galvanised Tube Handrail Standard
3C-550-550

Galvanised Tube Handrail Standard for M16 bolts

12mm flat drilled ø18 holes
for M16 bolts
(For B/C/D Tube)


Galvanised Tube Handrail Standard
4D-550-550

Galvanised Tube Handrail Standard for M16 bolts

10mm flat drilled ø18 holes
for M16 bolts
(For B/C/D Tube)


Adjustable Railings - Galvanised

adjustable railings

The pivot point offers an adjustable angle to handrail standards, allowing for instant installation of handrail on slopes, so no more waiting for the fabrication of costly raked standards.
Load tested.
No fabrication of raked specials required.
Flexible on site adjustment
.

Adjustable Rail
FHB2B

adjustable handrail for B or C tube

(For B/C Tube)


Adjustable Rail
FHB3C

adjustable handrail for B or C tube

(For B/C Tube)


Adjustable Rail
FHB4D

adjustable handrail for B or C tube

(For B/C Tube)


Pre-assembled safety posts
for 'C' tube

These pre-assembled tube clamp posts help reduce installation time.

They are supplied in a standard height of 1100mm and constructed using 'C' tube (Ø42.4mm).

Used in conjunction with tube cross rails of 1450mm, they conform to Building Regulations.

1603001C
End post
assembled

Pre-assembled end post for C tube

'C' tube
1100mm ø42.4

£47.50

1603002C
Middle post assembled

Pre-assembled middle post for C tube

'C' tube
1100mm ø42.4

£51.58

1603003C
Corner post
assembled

Pre-assembled corner post for C tube

'C' tube
1100mm ø42.4

£52.78

Pre-assembled safety posts
for 'D' tube

These pre-assembled tube clamp posts help reduce installation time.

They are supplied in a standard height of 1100mm and constructed using 'D' tube (Ø48.3mm).

Used in conjunction with tube cross rails of 1450mm, they conform to Building Regulations.

1603001D
End post
assembled

Pre-assembled end post for D tube

'D' tube
1100mm ø48.3

£47.50

1603002D
Middle post assembled

Pre-assembled middle post for D tube

'D' tube
1100mm ø48.3

£51.58

1603003D
Corner post
assembled

Pre-assembled corner post for D tube

'D' tube
1100mm ø48.3

£52.78

Disabled Access Range

The DDA Range is designed to meet the requirements of part 'M'
of the Building Regulations 2004 regarding provisions for disabled people.

The DDA range conforms to the requirement for smooth continuous handrail
using 42.4mm O/D galvanised tube.

The Building Regulations state the rail shall be between 40 and 45mm O/D.

All fittings are cast iron and galvanised to BS EN ISO 1461.

Suitable for stairs, ramps and walkways.

For uprights use Type D tube (48.3mm). For horizontals use Type C tube (42.4mm).

DDA01
Upright connector

Upright connector for disabled access handrails

To attach the 'DDA04 INTERMEDIATE BRACKET' or the 'DDA02 HANDRAIL CONNECTOR' to the 48.3mm o/d upright.

£10.88

DDA02
Handrail curve

Handrail curve for disabled access handrails

To attach the end of the 42.4mm o/d handrail tube at 90° to the 48.3mm
o/d upright. Used in conjunction with DDA01 UPRIGHT CONNECTOR and DDA07 INTERNAL CONNECTOR.

£15.00

DDA03
Wall bracket

Wall bracket for disabled access handrails

To support 42.4mm o/d handrail tube to a wall. The tube is fixed to this WALL BRACKET using either 2 x self tapping screws or 2 x pop rivets.

£16.16

DDA04
Intermediate bracket

Intermediate bracket for disabled access handrails

To support the top or middle rail tube at an upright in conjunction with a 'DDA01 UPRIGHT CONNECTOR'. The 42.4mm o/d tube is fixed to this fitting using either 2 x self tapping screws or 2 x pop rivets.

£16.20

DDA05
End return

End return for disabled access handrails

For terminating the 42.4mm o/d handrail tube back to a wall. Used in conjunction with a DDA07 INTERNAL CONNECTOR.

£13.25

DDA06
90° Bend

90° Bend for disabled access handrails

Expanding elbow for creating a smooth 90° bend in the 42.4mm o/d tube.

£18.60

DDA07
Internal connector

Internal connector for disabled access handrails

Expanding internal connector for joining sections of 42.4mm o/d tube, or other DDA fittings.

£5.98

DDA08
End cap - plastic

Plastic end cap for disabled access handrails

48.3mm o/d plastic end cap for inserting into the open tube on the top of the upright. For a permanent fix, a suitable adhesive should be used.

76p

DDA09
Adjustable bend

Adjustable bend for disabled access handrails

For creating an adjustable bend between the horizontal and the vertical.

£25.95

DISABLED ACCESS HANDRAIL DISABLED ACCESS HANDRAIL DISABLED ACCESS HANDRAIL DISABLED ACCESS HANDRAIL

Selector Guide for LEVEL Handrail

key clamp selector guide - LEVEL HANDRAIL

Selector Guide for SLOPING Handrail

key clamp selector guide - SLOPING HANDRAIL



© www.ironfinials.co.uk 2009-present date.
Our Terms & Conditions are simple: you pay us & we promise to deliver exactly what you have ordered.
Click here for Return, Cancellation & Delivery Policies.
Bexhill Steelwoks, Unit 3, Breadsell Farm, St Leonards-on-Sea, TN38 8EB.
Registered in England - Company No. 05368388. VAT No. 850735425.

email view basket
